PE Cosmetic Bottle 420ml
Download the complete PE / HDPE bottle catalog PDF.
Full engineering parameters for SJE1869-420. Nominal factory values — custom colors, printing and finishing available on all parameters below.
| Dimensions & Capacity | |
| Nominal Capacity | 420 ml (14.2 fl oz) |
| Overflow Capacity (brimful) | 448 ml (15.1 fl oz) |
| Bottle Weight | 45 g |
| Neck Finish | 32/410 |
| Total Height | 143 mm |
| Shoulder Height | 129 mm |
| Base (W × D) | 72 × 72 mm |
| Material & Compliance | |
| Material | PE/HDPE |
| Resin Grade | Food-contact, virgin (non-recycled) |
| Certifications | ISO 9001 / FDA / SGS |
| Recyclable | Yes |
| Packing & Order Info | |
| Carton Pack | Confirmed per order — contact us for exact carton specs |
| MOQ | 5,000 units |
| Lead Time | 15–25 days |
Typical applications for this mid-size HDPE bottle: shampoo, conditioner, body wash, hand soap and general personal-care packaging. HDPE resists everyday chemicals and squeezes cleanly to the last drop.
SJE1869-420 is a 420 ml PE / HDPE bottle in the body & hair-care size range. It suits sunscreen, opaque lotions, body wash and chemical-sensitive formulations, and is commonly specified for body lotions, shampoos, conditioners and shower gels. It works with standard screw, pump or flip-top closures to match your filling line.
For branding, silk-screen, hot-stamp and in-mold labeling are available on this PE / HDPE body. Pair it with a screw, pump or flip-top closure to complete a shelf-ready package at a 5,000 units MOQ, produced on ISO 9001 / FDA / SGS certified lines.
SJE1869-420 is 143 mm tall on a 72 x 72 mm base, so the height is 1.99 times the widest base dimension and the footprint is 51.8 cm².
| Total height | 143 mm |
|---|---|
| Base (W x D) | 72 x 72 mm |
| Footprint | 51.8 cm² |
| Height to widest base | 1.99 : 1 |
| Average content per mm | 2.94 ml |
| Empty weight per 100 mm | 31.47 g |
| Empty weight per litre held | 107.1 g |
| Headspace above nominal | 28 ml (6.2%) |
SJT0336-420 is the closest thing we mould to SJE1869-420 at 420 ml: 15 mm taller; a 74 x 74 mm base against 72 x 72 mm here; 6 g lighter. Moving between the two needs no new tooling.
| SKU | SJT0336-420 |
|---|---|
| Capacity | 420 ml (14.2 fl oz) |
| Height | 158 mm |
| Base | 74 × 74 mm |
| Neck | 32/410 |
| Weight | 39 g |
Stated capacity on SJE1869-420 is 420 ml and the brimful figure is 448 ml, so 28 ml of headspace sits under the rim, inside a body 143 mm tall. Holding the filler at a 90% line puts 378 ml in every unit, so a 500 L batch fills 1,322 of them.
| Batch of product | 420 ml units at 90% | Resin for those units |
|---|---|---|
| 500 L | 1,322 | 59.5 kg |
| 1,000 L | 2,645 | 119 kg |
| 5,000 L | 13,227 | 595.2 kg |
5,000 units of SJE1869-420 is 2,100 L of finished product, and 100,000 units is 42,000 L, which takes 4,500 kg of resin at 45 g a bottle. MOQ is per colour rather than per SKU. 143 mm and 420 ml formats can share one colour. Lead time is 15–30 days from sample sign-off and deposit.
Tell us your quantity and target market — our engineering team replies within 2 working hours with pricing, lead time and samples. No registration required.
